Home>Philips Feeder Assembleon
Type Part number Depth (mm) Feeding pitch (mm)
PHILIPS FEEDER ASSEMBLEON GEM
8mm 01005 CL Tapefeeder 9498 396 02008 PA 2903-96
8mm feeder for 01005, 2mm pitch, Green Handle Yellow Band CL-822-15		 2.5
 2
8mm 0201 CL Tapefeeder Part nr.: 9498 396 00339 PA 2903-77
8mm feeder for 0201, 2mm pitch Green Handle CL-823-15
8mm 0402 CL Tapefeeder Part nr.: 9498 396 00340
Alternate Part Number: 9498 396 00498
PA2903-78
8 mm feeder for 0402, 2mm pitch, reel Blue Handle CL-825-15		 2.5
 2
8mm Standard CL Tapefeeder Part nr.: 9498 396 00341 PA 2903-79
8 mm feeder, STD, 4mm pitch, reel Black Handle CL-84-15		 2.5
 4
12mm CL Tapefeeder Part nr.: 9498 396 00342 PA 2903-88 12mm CL feeder, 4-12mm pitch, 15" Reel Holder Black Handle CL-12 2.5 4,8,12
16mm CL Tapefeeder Part nr.: 9498 396 00338 PA 2903-27
16mm feeder, 4-16mm pitch, 15" Reel Holder Black Handle CL-16		 11 4,8,12,16
24mm CL Tapefeeder Part nr.: 9965 000 15825 PA 2903-38
24mm feeder, 4-24mm pitch, 15" Reel Holder CL-24		 15
 4,8,12,16,20,24
32mm CL Tapefeeder Part nr.: 9965 000 15826 PA 2903-48
32mm feeder, 8-32 mm pitch, 15" Reel Holder CL-32		 15
 4,8,12,16,20,24,28,32
PHILIPS FEEDER ASSEMBLEON GEM
44mm CL Tapefeeder Part nr.: 9965 000 15827 PA 2903-58
44mm feeder, 8-36 mm pitch, 15" Reel Holder CL-448		 15
 4,8,12,16,20,24,28,32,36
56mm CL Tapefeeder Part nr.: 9965 000 15828 PA 2903-68
56mm feeder, 8-36mm pitch, 15" Reel Holder CL-56 		15
 4,8,12,16,20,24,28,32,36
72MM CL Tapefeeder Part nr.: 9498 396 01977 PA 2903-67
72 6mm feeder, 8-36mm pitch, 15" Reel Holder CL-72		 15 4,8,12,16,20,24,28,32,36

PHILIPS FEEDER ASSEMBLEON GEM 8*2

8mm 0402 CL Tapefeeder 8mm 0402 CL Tapefeeder Part nr.: 9498 396 00340 2903-78 8 mm feeder for 0402, 2mm pitch, reel Blue Handle CL-825-15
philips feeder philips feeder
PHILIPS FEEDER ASSEMBLEON GEM 8*4 8mm Standard CL Tapefeeder 8mm Standard CL Tapefeeder Part nr.: 9498 396 00341 PA 2903-79 8 mm feeder, STD, 4mm pitch, reel Black Handle CL-84-15
PHILIPS FEEDER FOR ASSEMBLEON GEM 8*2 FOR 0201(1005)
8mm 0201 CL Tapefeeder
Part nr.: 9498 396 00339 PA 2903-77 8mm feeder for 0201, 2mm pitch Green Handle CL-823-15 		12mm CL Tapefeeder
Part nr.: 9498 396 00342 PA 2903-88 12mm CL feeder, 4-12mm pitch, 15" Reel Holder Black Handle CL-12
YAMAHA CL FEEDER 12MM
16mm CL Tapefeeder
Part nr.: 9498 396 00338 PA 2903-27 16mm feeder, 4-16mm pitch, 15" Reel Holder Black Handle CL-16		 24mm CL Tape Feeder
Part nr.: 9965 000 15825 PA 2903-38 24mm feeder, 4-24mm pitch, 15" Reel Holder CL-24 		32mm CL Tapefeeder
Part nr.: 9965 000 15826 PA 2903-48 32mm feeder, 8-32 mm pitch, 15" Reel Holder CL-32
YAMAHA CL FEEDER 16MM YAMAHA CL FEEDER 32MM YAMAHA CL FEEDER 32MM
44mm CL Tapefeeder
Part nr.: 9965 000 15827 PA 2903-58 44mm feeder, 8-36 mm pitch, 15" Reel Holder CL-44 		56mm CL Tapefeeder
Part nr.: 9965 000 15828 PA 2903-68 56mm feeder, 8-36mm pitch, 15" Reel Holder CL-56
72mm CLi Tapefeede
Part nr.: 9498 396 01977 PA 2903-67 72mm feeder, 8-36mm pitch, 15" Reel Holder CLi-72
YAMAHA CL FEEDER 44MM YAMAHA CL FEEDER 56MM YAMAHA FEEDER

FS2 8*2
FT 8*2
PHILIPS ASSEMBLEON FEEDER PART
PHILIPS ASSEMBLEON FEEDER PART
PHILIPS ASSEMBLEON GEM VIBRATORY FEEDER
VIBRATORY FEEDER YAMAHA STICK FEEDER
PHILIPS ASSEMBLEON GEM IC TRAY

PHILIPS ASSEMBLEON GEM FEEDER STORAGE TROLLEY ,CART

PHILIPS ASSEMBLEON GEM FEEDER CALIBRATION JIG
feeder calibration jig
Through years of efforts, we've developed Philips Assembleon GEM series SMT feeder(Topaz ,Emerld, Opal, Sapphire,) ,including
1. Philips CL 8x2mm Feeder KW1-M1300-020
2. Philips GEM 08x02 Feeder PA2903/74
3. Philips GEM 8mm Feeders PA2903/79
4. Philips GEM 12mm Feeders PA2903/
5. Philips GEM 16mm Feeders Variable Pitch
6. Philips GEM 24mm Feeders PA2903/79
7. Philips GEM 32mm Feeders PA2903/79
8. Philips GEM 44mm Feeders PA2903/79
9. Philips GEM 56mm Feeder
10. Philips GEM 72mm Feeder
11. Philips CL 8x2mm Feeders for 0201 components
These products look not only in apperance but also in quality are quite the same as original ones.We also offer you all Philips feeder spare parts, such asTAPE GUIDE ASSY, BACK STOPPER,SPROCKET AXIS ASSY,MULTI CYLINDER,SPRING,KNOCK PIN,INDENTATION LVR ASSY,DRIVE ROLLER ASSY,IDLE ROLLER ASSY and so on.
PHILIPS FEEDER PART LIST--CL TYPE
PHILIPS FEEDER PART LIST--FV TYPE
PHILIPS ASSEMBLEON GEM SMT NOZZLE
PHILIPS ASSEMBLEON GEM SMT SPARE PART
